工業產業應用
SMD Shielded Type (Ferrite Core)
| Series | Dimensions (L*W*T)mm | Inductance (uH) | Tolerance (±%) | Rated Current(A) |
|---|---|---|---|---|
| S1530-H129R-4R7M | 12.2 x 12.2 x 9.6 | 4.7 | 20 | 7.0 |
| S841-H124R-150M | 12.0 x 12.0 x 4.6 | 15 | 20 | 3.2 |
| S809-H8D43-6R8M | 8.5 x 8.3 4.5 | 6.8 | 20 | 3.0 |
| S741-H74R-3R3M | 7.3 x 7.3 x4.5 | 3.3 | 20 | 3.5 |
⟵
DC-DC Converters
| Series | Dimensions (L*W*T)mm | Input Voltage Range（Vdc） | Output Voltage（Vdc） | Output Current（mA） |
|---|---|---|---|---|
| AD0505D-01A | 19.5 x 6.0 x 10.0 | 4.5~5.5 | 5.0 | 100 |
| AD0303S-01A | 11.5 x 6.0 x 10.0 | 2.97~3.63 | 3.3 | 152 |
⟵
